Sun Rock RAS 1000 is a DTH cum Rotary water well drilling rig with 6½"–20" diameter capacity, 1000m depth, 31,000 kgf pull-down, 1170 kg·m torque, 0–100 RPM, powered by 1500cfm/400psi or 1200cfm/350psi compressor, and a high-pressure duplex mud pump.
| Application | Domestic Water Wells |
|---|---|
| Drilling Method | DTH / Rotary Drilling |
| Flushing Medium | Air / Water |
| Drilling Depth | 180 m @ 165 mm |
| Hole Diameter | 165 - 203 mm (6 ½" - 8") |
| Rod Handling Method | Single rod changer |
| Rotary Head Type | Top drive rotary head |
| Rotary Head Travel | 5000 mm |
| Rod Break out method | Hydraulic operated breakout system |
| Engine - Model | Suitable Deck Engine 105 hp |
| Hydraulic system | Hydraulic Oil Cooler: 70 gpm , Hydraulic Tank Capacity: 300 litres |
| Mounting | Truck / Crawler / Skid |
| Drilling Method | Rotary Auger Drilling |
| Drilling Dia | 6 1/2" - 20" |
|---|---|
| Drilling Depth | 1000MTRS |
| Pull Up Force | 31000kgf |
| Pull Down Force | 22000kgf |
| Rotary Drive and RPM | 1170kgs mtr-torque,0-100rpm |
| Compressor | 1500cfm/400psi (or) 1200cfm/350psi |
| Drilling operation | DTH cum Rotary Drilling |
| Optional Fittings | High Pressure engine driven duplex double-acting mud pump |
